Hidden Markov Model

Markov Chain

---

• The Markov Property is a property in which past information is concentrated in the current state, so that the future state is independent of the past state conditionally on the current state.

  \[\begin{gathered} X(t+1)\perp X(0),X(1),\cdots,X(t-1)\mid X(t) \end{gathered}\]

• For a random variable sequence \(\{X(t):t\in T\}\) defined on a discrete time space \(t\in T\) and a discrete state space \(S=\{k\}_{k=1}^{K}\), if this sequence is a stochastic process that satisfies the Markov Property, it is defined as a Markov Chain.

  \[\begin{gathered} P[X(t+1)\mid X(0),X(1),\cdots,X(t-1),X(t)] =P[X(t+1)\mid X(t)] \end{gathered}\]

• discrete state probability is the possibility that at time $t$ the random variable $X(t)$ will take a specific state $i$.

  \[\pi_{i}(t)=P[X(t)=i]\]

• transition probability is the possibility that the future state $t+1$ will change to $j$ when the current state $t$ is realized as $i$.

  \[\begin{aligned} \alpha_{i,j} =P[X(t+1)=j\mid X(t)=i] \end{aligned}\]

• discrete state distribution vector \(\Pi(t)\) is updated through multiplication with the transition probability matrix \(\mathbf{A}\).

  \[\begin{aligned} \Pi(t+1) &=\Pi(t)\mathbf{A} \end{aligned}\]

• The possibility that a Markov Chain will maintain a specific state in the long run is called the Steady-State Probability.

  \[\begin{aligned} \Pi(t)\xrightarrow{t\to\infty}\Pi, \quad\Pi=\Pi\mathbf{A} \end{aligned}\]

Hidden Markov Model

---

• Let the observation $Y$ occur conditionally on the latent factor $X$, and let this latent factor $X$ be a Markov chain. This model is called a Hidden Markov Model.

  \[\begin{gathered} P(X,Y)=P(Y\mid X)P(X) \quad\mathrm{for}\quad X(t)\perp X(1),\cdots,X(t-1)\mid X(t) \end{gathered}\]

• Optimization of Hidden Markov Model is performed using the EM Algorithm.

  \[\Theta^{(s+1)} =\mathrm{arg}\max_{\Theta}{Q(\Theta\mid\Theta^{(s)})}\]

• The parameters are the initial state probability $\pi_{k}$, transition probability $\alpha_{i,j}(\forall t)$, and emission probability $\beta_{k}(t)$.

  \[\Theta :=\left\{\pi_{k}\in\Pi,\alpha_{i,j}\in\mathbf{A},\beta_{k}(t)\in\mathbf{B}\right\}\]

• Specifically, the latent variables are (1) the probability that the hidden state $X(t)=k$ is present at each point and (2) the probability that the transition event occurring at each point is $i\to j$, given the obs $Y$.

  \[\begin{aligned} \mu_{k}(t) &=P[X(t)=k\mid Y(1),\cdots,Y(T)]\\ \gamma_{i,j}(t) &=P[X(t+1)=j,X(t)=i\mid Y(1),\cdots,Y(T)] \end{aligned}\]

definition

---

• Hidden State:

  \[\begin{aligned} X(1),X(2),\cdots,X(T) \end{aligned}\]

• Observed State:

  \[\begin{aligned} Y(1),Y(2),\cdots,Y(T) \end{aligned}\]

• Initial State:

  \[\begin{aligned} \pi_{i}(1):=P[X(1)=i] \end{aligned}\]

• The transition probability represents the possibility that the hidden state will transition from $i\to j$.

  \[\begin{aligned} \alpha_{i,j} :=P[X(t+1)=j\mid X(t)=i] \end{aligned}\]

• The emission probability represents the possibility that the observed state $Y(t)$ will be realized at point $t$ when the hidden state $X(t)=j$ is realized at that point.

  \[\begin{aligned} \beta_{j}(t) :=P[Y(t)\mid X(t)=j] \end{aligned}\]

forward probability

---

• The forward probability is expressed as a joint probability as the possibility that the observed state from the beginning to point $t$ and the hidden state at point $t$ will be realized in a specific form.

  \[\begin{aligned} \phi_{j}(t) :=P[\underbrace{Y(1),\cdots,Y(t)}_{\text{obs}};\underbrace{X(t)=j}_{\text{latent factor}}] \end{aligned}\]

• initial expression ($t=1$):

  \[\begin{aligned} \phi_{j}(1) &=P[Y(1);X(1)=j]\\ &=P[X(1)=j]\cdot P[Y(1)\mid X(1)=j]\\ &=\pi_{j}(1)\beta_{j}(1) \end{aligned}\]

• factorization:

  \[\begin{aligned} \phi_{i}(t-1) &=P[Y(1),\cdots,Y(t-1);X(t-1)=i]\\ \alpha_{i,j} &=P[X(t)=j\mid X(t-1)=i]\\ \beta_{j}(t) &=P[Y(t)\mid X(t)=j] \end{aligned}\]

• recursion ($t\to t+1$):

  \[\begin{aligned} \phi_{j}(t) &=P[Y(1),\cdots,Y(t);X(t)=j]\\ &=\sum_{i=1}^{K}{P[Y(1),\cdots,Y(t);X(t)=j,X(t-1)=i]}\\ &=\beta_{j}(t)\cdot \sum_{i=1}^{K}{\phi_{i}(t-1)\cdot\alpha_{i,j}} \end{aligned}\]

• final expression ($t=1,\cdots,T$):

  \[\begin{aligned} P[Y(1),\cdots,Y(T)] &=\sum_{j=1}^{K}{P[Y(1),\cdots,Y(T);X(T)=j]}\\ &=\sum_{j=1}^{K}{\phi_{j}(T)} \end{aligned}\]

backward probability

---

• The backward probability is expressed as a conditional probability as the possibility that the observed state will be realized in a specific form from point $t+1$ onwards when the hidden state at point $t$ is realized in a specific form.

  \[\begin{aligned} \psi_{j}(t) :=P[\underbrace{Y(t+1),\cdots,Y(T)}_{\text{obs}}\mid\underbrace{X(t)=j}_{\text{latent factor}}] \end{aligned}\]

• final expression ($t=T$):

  \[\begin{aligned} \psi_{j}(T) =P[X(T)=j] =1 \end{aligned}\]

• factorization:

  \[\begin{aligned} \alpha_{i,j} &=P[X(t+1)=j\mid X(t)=i]\\ \beta_{j}(t+1) &=P[Y(t+1)\mid X(t+1)=j]\\ \psi_{j}(t+1) &=P[Y(t+2),\cdots,Y(T)\mid X(t+1)=j] \end{aligned}\]

• recursion ($t+1\to t$):

  \[\begin{aligned} \psi_{i}(t) &=P[Y(t+1),\cdots,Y(T)\mid X(t)=i]\\ &=\sum_{j}{P[Y(t+1),\cdots,Y(T);X(t+1)=j\mid X(t)=i]}\\ &=\sum_{j}{\alpha_{i,j}\cdot\beta_{j}(t+1)\cdot\psi_{j}(t+1)} \end{aligned}\]

latent factor posterior

---

state posterior

• 1 point state posterior:

  \[\begin{aligned} \mu_{j}(t) &=P[X(t)=j\mid Y(1),\cdots,Y(T)] \end{aligned}\]

• factorization:

  \[\begin{aligned} \phi_{j}(t) &=P[Y(1),\cdots,Y(t);X(t)=j]\\ \psi_{j}(t) &=P[Y(t+1),\cdots,Y(T)\mid X(t)=j]\\ \sum_{k}{\phi_{k}(T)} &=P[Y(1),\cdots,Y(T)] \end{aligned}\]

• transformation:

  \[\begin{aligned} \mu_{j}(t) &=P[X(t)=j\mid Y(1),\cdots,Y(T)]\\ &=\frac{P[Y(1),\cdots,Y(T);X(t)=j]}{P[Y(1),\cdots,Y(T)]}\\ &=\frac{\phi_{j}(t)\cdot\psi_{j}(t)}{\sum_{k}{\phi_{k}(T)}} \end{aligned}\]

transition event posterior

• $i\to j$ transition event posterior:

  \[\begin{aligned} \gamma_{i,j}(t) &=P[X(t+1)=j,X(t)=i\mid Y(1),\cdots,Y(T)] \end{aligned}\]

• factorization:

  \[\begin{aligned} \phi_{i}(t) &=P[Y(1),\cdots,Y(t);X(t)=i]\\ \alpha_{i,j} &=P[X(t+1)=j\mid X(t)=i]\\ \beta_{j}(t+1) &=P[Y(t+1)\mid X(t+1)=j]\\ \psi_{j}(t+1) &=P[Y(t+2),\cdots,Y(t)]\\ \sum_{k}{\phi_{k}(T)} &=P[Y(1),\cdots,Y(T)] \end{aligned}\]

• transformation:

  \[\begin{aligned} \gamma_{i,j}(t) &=P[X(t+1)=j,X(t)=i\mid Y(1),\cdots,Y(T)]\\ &=\frac{P[Y(1),\cdots,Y(T);X(t+1)=j,X(t)=i]}{P[Y(1),\cdots,Y(T)]}\\ &=\frac{\phi_{i}(t)\cdot\alpha_{i,j}\cdot\beta_{j}(t+1)\cdot\psi_{j}(t+1)}{\sum_{k}{\phi_{k}(T)}} \end{aligned}\]

E-M Algorithm

---

• parameters:

  \[\Theta :=\left\{\pi_{k}\in\Pi,\alpha_{i,j}\in\mathbf{A},\beta_{k}(t)\in\mathbf{B}\right\}\]

• complete-data expected log-likelihood:

  \[\begin{aligned} \mathbb{E}_{q(X)}[\log{P(Y,X\mid\theta)}] &=\underbrace{\mathbb{E}_{q(X)}[\log{P(Y\mid X,\theta)}]}_{\text{log emission prob.}}+\underbrace{\mathbb{E}_{q(X)}[\log{P(X\mid\theta)}]}_{\text{log transition prob.}} \end{aligned}\]

• emission prob.

  \[\begin{aligned} \mathbb{E}_{q(X)}[\log{P(Y\mid X,\theta)}] &=\underbrace{q(X)}_{\text{state prob.}}\cdot\underbrace{\log{P[Y(t)\mid X(t)=k]}}_{\text{log emission prob.}}\\ &=\mu_{k}(t)\cdot\log{\beta_{k}(t)} \end{aligned}\]

• transition prob.

  \[\begin{aligned} \mathbb{E}_{q(X)}[\log{P(X\mid\theta)}] &=\underbrace{q(X)}_{\text{event prob.}}\cdot\underbrace{\log{P[X(t+1)=j\mid X(t)=i]}}_{\text{log transition prob.}}\\ &=\gamma_{i,j}(t)\cdot\log{\alpha_{i,j}(t)} \end{aligned}\]

• init prob.

  \[\begin{aligned} \mathbb{E}_{q(X)}(\log{P[X(1)=k]}) &=\underbrace{q(X)}_{\text{state prob.}}\cdot\underbrace{\log{P[X(1)=k]}}_{\text{log init prob.}}\\ &=\mu_{k}(1)\cdot\log{\pi_{k}} \end{aligned}\]

• Q function:

  \[\begin{aligned} Q(\Theta\mid\Theta^{(s)}) &=\sum_{t=1}^{T}\sum_{k=1}^{K}{\mu_{k}(t)\cdot\log{\beta_{k}(t)}}\\ &\quad +\sum_{t=1}^{T-1}\sum_{i=1}^{K}\sum_{j=1}^{K}{\gamma_{i,j}(t)\cdot\log{\alpha_{i,j}(t)}}+\sum_{k=1}^{K}{\mu_{k}(1)\cdot\log{\pi_{k}}} \end{aligned}\]

• MLE parameter update:

  \[\Theta^{(s+1)} =\mathrm{arg}\max_{\Theta}{Q(\Theta\mid\Theta^{(s)})}\]
